🔧 Civic - Spark Plug Replacement

Your Civic’s spark plugs wear over time and can cause rough idle, poor fuel economy, and misfires. Replacing them is straightforward because they’re on top of the engine under the ignition coils.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and to protect aluminum threads.
• ⚠️ Keep dirt out of the spark plug wells; debris can fall into the cylinder.
• ⚠️ Do not over-tighten spark plugs—your Civic’s cylinder head is aluminum.
• ⚠️ Battery disconnect is not required, but if you choose to disconnect it, use a 10mm wrench and remove the negative terminal first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-30 ft-lbs range)
• 6" 3/8" drive extension
• 10mm socket
• 5/8" (16mm) spark plug socket
• Small flat trim tool
• Compressed air blow gun
• Feeler gauge (0.039"-0.043")
• Dielectric grease applicator
• Magnetic pickup tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (iridium, OEM-style) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Let the engine cool completely (at least 1 hour after driving).
• Open the hood and remove loose items from the cowl area so nothing falls into the engine bay.
• Take a quick photo before unplugging anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Use a 10mm socket to remove the engine cover fasteners (if present), then lift the cover off.

Step 2: Unplug the ignition coils

• Each spark plug has an ignition coil on top (a coil is the part that makes the high-voltage spark).
• Use a small flat trim tool to gently lift the electrical connector lock tab, then pull the connector straight off.

Step 3: Remove the ignition coils

• Use a 10mm socket to remove the coil hold-down bolt on each coil.
• Twist the coil slightly and pull straight upward to remove it from the spark plug well.
• Set coils aside in order (so each coil goes back to the same cylinder).

Step 4: Clean the spark plug wells

• Use a compressed air blow gun to blow out each spark plug well before removing the plug.
• This prevents grit from dropping into the engine when the plug comes out.

Step 5: Remove the old spark plugs

• Install the 5/8" (16mm) spark plug socket on the 6" 3/8" drive extension and 3/8" drive ratchet.
• Turn counterclockwise to loosen, then continue until the plug is free.
• If a plug feels stuck, stop and apply steady pressure—don’t force it.
• Use a magnetic pickup tool only if needed to lift a loose plug (careful not to chip the porcelain).

Step 6: Check the new spark plug gap

• Use a feeler gauge (0.039"-0.043") to verify the gap is about 0.039"-0.043" (1.0-1.1 mm).
• Most iridium plugs come pre-gapped—avoid bending the tiny center electrode.
• If the gap is off, exchange the plug.

Step 7: Install the new spark plugs (start by hand)

• Place a new plug into the 5/8" (16mm) spark plug socket.
• Thread it in by hand using the 6" 3/8" drive extension only (no ratchet at first).
• If it doesn’t turn easily, back it out and start again (this prevents cross-threading).
• Once hand-tight, use a 3/8" drive torque wrench to tighten: Torque to 18 Nm (13 ft-lbs).

Step 8: Reinstall the ignition coils

• Apply a very small amount of dielectric grease with the dielectric grease applicator inside the rubber boot (dielectric grease helps prevent moisture and makes future removal easier).
• Push each coil straight down until it fully seats on the plug.
• Install the coil hold-down bolts using a 10mm socket, then tighten with a 3/8" drive torque wrench: Torque to 12 Nm (9 ft-lbs).

Step 9: Plug the connectors back in

• Push each connector on until it clicks and the lock tab is secure.
• Do a quick look across the top to confirm all 4 coils are bolted and plugged in.

Step 10: Reinstall the engine cover

• Set the cover back in place and tighten fasteners with a 10mm socket (snug, do not over-tighten).

---

✅ After Repair

• Start the engine and let it idle for 1-2 minutes; it should run smooth with no shaking.
• If the engine runs rough, turn it off and re-check that every coil connector is fully seated.
• Take a short test drive and confirm there’s no check engine light.
• Keep the old plugs to compare color/condition later.

---

💰 DIY vs Shop Cost

Shop Cost: $200-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $160-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
